; Racket examples from CS 111 - Week 1 Lecture 2,
; cleaned up after class!
; last modified: 2025-08-28
; this is a comment!
; (syntax: anything from a semicolon to the end of the line)
; * comments are IGNORED by the computer!
; * they are there for HUMANS to read
;=====
; data type: number
; can have digits smushed together,
; optionally with a single . decimal point
; optionally starting with a + or -
; (there are a few other possibilities, also...)
; here are some simple expressions of type number
8
14
10
19
e
pi
41.113
-12
+12
; can't have a space between a leading - or + and a digit;
; this attempted simple expression below does NOT follow
; the syntax ruls for a number;
; UNCOMMENT the line below (REMOVE the ;) and click run
; to see the error message you get!
; + 12
; this also does NOT follow number syntax:
; 41.1.1
;=====
; in BSL Racket, you can separate expressions using blanks
; as well as newlines
; below: eight simple expressions of data type number
1 2 3 4 5 -7 5555 .45
;=====
; data type: string
; syntax: anything written in double quotes is considered
; a simple expression literal of type string
"moo"
"12"
"can I say \"Hi\"?"
;=====
; data type: boolean
; consists of just two values!
; for BSL Racket: the syntax for the most-basic literal simple
; expressions of type boolean
; are #true and #false
; BUT!!!! it also accepts true and #t for #true
; (considers true and #t to
; also have the value #true)
; it also accepts false and #f for #false
; (considers false and #f to
; also have the value #false)
; so - these are six simple expressions all of data type boolean
#true
#false
#t
#f
true
false
;=====
; data type: image
; syntax: you can paste in a copied
; .jpg or .png or .tiff or .svg
; image into DrRacket and that is considered a simple
; expression of type image
;=====
; I searched for "dachshund small image" in a browser,
; right-clicked on and copied the desired image in the
; browser results,
; then clicked on DrRacket's Interactions window,
; and used control/command v to paste in the image!
; (Edit menu -> Paste works, also)
; simple expression of type image
; NOTE: pasting in an image changes the Racket format "under the hood"
; in the .rkt file so that the image can be represented --
; in DrRacket it looks fine,
; but if you open the .rkt file in something OTHER than DrRacket,
; the format looks decidedly strange!
;=====
; compound expressions
;
; because we want to DO things! simple expressions alone are not
; enough!
;
; in BSL Racket, here is THE syntax for compound expressions:
;
; (operation argument-expression argument-expression argument-expression ...)
; ^ these expressions are called arguments
;
; operation is followed by at least one blank/newline,
; argument expressions are separated by at least one
; blank/newline
;
; semantics: what is the value of a compound expression?
; the value returned by its operation when that operation
; is executed using those argument expressions
;
; NOTE: the data type of a compound expression is the data type
; of the value its operation *returns*
; NOTE: it depends on the particular operation
; *how many* and
; *what data types* of argument expressions it expects,
; and *what order* they must be in
;=====
; some operations work on numbers and return numbers
;=====
; + is a supported operator for addition
;
; operator + expects two or more arguments of type number
; and returns the sum of it number arguments
(+ 3 4 5 6)
;=====
; more common arithmetic operators that Racket supports!
; each expects two more more argument expressions of type number,
; returns a value of type number that is the result of applying
; that operation to those argument expressions (in the order they
; appear)
;
; * multiply
; / divide
; - subtraction
(- 3 4)
(* 19 2)
(/ 2 19)
;=====
; BY THE WAY -- we said a compound expression expects one or more
; expressions after its operation;
; ...those argument expressions can be simple expressions *OR*
; compound expressions! As long as they are of the expected data type,
; they are fine!
(+ (- 3 4)
(* 19 2))
;=====
; some operations have names -- functions!
; and some operations return a value with a data type
; other than number!
; for example!
;=====
; string-append expects two or more string arguments
; and returns ONE string of those arguments' values
; all smushed together
(string-append "ether" "blue")
(string-append "ether" " " "blue")
; and an operation can expect arguments of one type but return
; a value of another type -- for example:
;=====
; string-length expects exactly one string argument
; and returns a number, the number of characters in
; that argument's string value
(string-length "ether")
; since string-length returns a number,
; a compound expression using it can be used anywhere
; a number expression can be used!
(+ (string-length "ether")
10)
;=====
; operators
; < > = <= >=
; expect two or more number arguments,
; return a boolean whose value is whether the number arguments
; meet that relationship
(> 3 5)
(< 3 5)
(= 3 (+ 1 2))
; and
; expects two or more boolean arguments,
; returns a boolean whose value is whether ALL of those
; have the value #true
(and (< 3 5) (> 10 5))
; or
; expects two or more boolean arguments,
; returns a boolean whose value is whether at least ONE
; of those has the value #true
(or (< 3 5) (> 3 5))
; not
; expects one boolean argument,
; and returns a boolean that is the opposite of that
; argument's value
(not #true)
(not (> 3 5))
;=====
; NOTE -- = operator ONLY works with argument expressions of type number!
; * but there ARE some operations to compare expressions of other types;
; * FOR EXAMPLE:
; string=? can be used to compare string expresssions, and returns
; whether its string argument expressions have the same value
(string=? "moo"
(string-append "m" "oo"))
;=====
; FUN FACT: DrRacket includes additional modules, collections of
; functions and other definitions;
; you can USE them by first using the special require operation
;
; require expects the name of a module,
; and, oddly, returns nothing,
; but has the side-effect of making everything defined in
; module now usable in the rest of its Definition window/.rkt file!
;
; for example: module 2htdp/image was written to support the
; "How to Design Programs", 2nd edition text,
; and includes a nice beginning collection of image-related
; operations!
; SO, I can use them after this expression:
(require 2htdp/image)
; for example:
; 2htdp/image's circle function expects a desired radius in pixels,
; the desired style expressed as a string: "solid" or "outline:,
; and a color (one option is to write a known color name as a string),
; and it returns an image depicting a circle image with that radius,
; style, and color!
(circle 113 "solid" "purple")
; for example:
; the beside function expects one or more images
; and returns a single image that is a horizontal "line"
; of the image argument expressions
(beside (circle 113 "solid" "purple")
(circle 113 "solid" "purple"))
;=====
; You can read about more of the operations/functions in
; the module 2htdp/image in the DrRacket documentation --
; * go to the DrRacket Help menu,
; * select "Racket Documentation" near the top,
; * enter in 2htdp/image in the ...search manuals... textfield
; in the top-left corner
; ...and select the link to the 2htdp/image module's documentation
; that results --
; ...scroll through the index on the left-hand-side, it has links to
; descriptions of the many functions in the 2htdp/image module!
